THE SECOND STAGE OF
BLAGOVESHCHENSKAYA CHP:
ROAD TO THE FUTURE

CHP is located near to con-

struction cranes and growing high-
rise buildings. It provides heat and
the necessary resources for 81%
of the population and industrial
enterprises in Blagoveshchensk
with a population of 224 thousand
people. But the city requires
new energy in order to develop
itself. It is necessary to build
a new CHP.

Impulse for the

С

onstruction

De

fi

 cit of the heat energy in Bla-

goveshchensk has been started
since early 2005. Due to the lack of
capacity, CHP of Bla go veshchensk
has stopped to connect new con-
sumers. Generally, it con

cerned

commercial structures. Developers,

Besides the fact that power supply provides comfort for the population, it also affects

the socio-economic development because the life of any production or residential

facility is impossible without heat and electricity. The project of construction of the

second stage of Blagoveshchenskaya combined heat and power (CHP) gave new

capacity for the capital of the Amur River region in order to make heat supply more

reliable and allow to connect new consumers.

New Energy

of the Far East


Page 3
background image

31

entrepreneurs and ordinary citi-
zens, who decided to build
a house in the city, appeal to CHP
of Blagoveshchensk every week.

The second stage of CHP of

Blagoveshchensk must solve
those problems.  In fact, this is
the expansion of the existing CHP
and installation of the modern
equipment.

“In order to avoid emergencies

by reason of the lack of a heat
capacity reserve, we were re-
fusing to connect new consumers
to the central heating during the
last years. Constructing hospitals,
schools, houses for orphans and
migrants connected to the power
system without any problem as
priority facilities, but we had to
refuse the owners of some com-
mercial or business centers, cot-
tages so that we will use available
capacity”, JSC “Far-eastern ge-
nerating company” General Direc-
tor Mikhail Shukaylov stated.

Undoubtedly, start of the

second stage of CHP has given
the impulse for the development of
the construction industry. There is
a prediction that the construction
area in Blagoveshchensk will
have been risen by more than two
million square meters by 2019.
There are such large investment
projects among those construction
area as the construction of two
entertainment complex for tourists
“Golden Mile” and “Little Venice”,
which will consume the heat from
CHP of Blagoveshchensk.

Almost 14 thousand standard

apartments are expected to get
heat from the new capacity this
year. It is one and a half time more
than it was built last year. Experts
have considered that due to new
capacities, Blagoveshchensk can
grow without problems.

Assistance for

Power Engineers

The power engineers, who

work for CHP, waited for the se-
cond stage of the CHP. One of the
unique features of Blago vesh chen-
skaya CHP was the fact that it was
working for the last seven years
using all equipment of that CHP

and having as reserve only two
hot water boilers. CHP was work-
ing in this mode during all four cold
months of those years. Any equip-
ment failure could create dif

fi

 cul-

ties for the city. Installed capacity
was 280 MW and installed heat ca-
pacity was 817 Gcal/h. Under the
conditions of high requirements to
the hardware, staff ’s responsibi-
lity increases. There was no right
to make a mistake, because CHP

of Bla goveshchensk provides al-
most three-quarters of heat sup-
ply for the city. That is why winter
had been the most tough working
time for the power engineers from
Blagoveshchensk before the start
of the new equipment operation of
the second stage of CHP. Today
power engineers say with con

fi

 -

dence that the issue of risks of
CHP uninterrupted operation has
been solved.

2nd stage of BLAGOVESHCHENSKAYA CHP

•

Objectives:

•

the elimination of the de

fi

 cit and cover of the future require-

ments for the heat capacity in Blagoveshchensk,

•

the replacement of inef

fi

 cient municipal boilers and the

connection of the new residential areas to the district
heating of Blagoveshchensk

•

Electrical capacity:

120 MW

 (2nd stage)

•

Heat capacity:



188 Gcal/h

 (2nd stage)

•

Fuel:

coal from “Erkovetsky”

fi

 eld

•

Р

opulation of the

Amur River region:



800 thousand people

•

Р

opulation

of Blagoveshchensk:



220 thousand people

Construction of new boiler unit of the
power plant second stage

Fa

c

t s

h

e

e

t


Page 4
background image

32

Way from

the Project to

the Results

In fact, the second stage of

CHP of Blagoveshchensk is the
expansion of capacity of the
existing CHP. CJSC “COTES”
(from Novosibirsk) and CJSC
“Lonas Tekhnologia” became
the general designers of the
project, JSC “Power machines”
was the general contractor. JSC
“Blagoveshchenskaya CHP”
(subsidiary of PJSC “RusHydro”
managed by PJSC “RAO Energy
Systems of the East”) became
customer and developer.

Project of the construction of

the CHP second stage included in-
stallation of the

fi

 fth boiler and the

fourth turbine set, construction of
the fourth cooling tower, instal lation
of additional transformers and ex-
pansion of outdoor switchgear,
modernization of the fuel-handling
system with expansion for the
boiler number 5 and con struction
about 7 km of railway lines.

The project in Blagovesh-

chensk has a particular feature in

comparison with constructions in
Sakhalin, Yakutia the Khabarovsk
Territory. The construction in
Blagoveshchensk took place on
the area of the operating power
plant. The new equipment was
embedded in the existing building
and in the important industrial pro-
cess without stopping. By reason
of the project of the CHP

fi

 rst stage

included the construction of the
main building for the expansion of
capacity in the future, the decision
was made to use the same kind
of equipment as already working
one.

The new unit of CHP is fully

automated. There are no switch
buttons anymore. A monitor is
located in front of operating staff.
They can get any circuit as well as
switch on and switch off different
nodes by means of a computer
mouse. All processes on the new
equipment of the power plant are
ful

fi

 lled by means of automatic

process control system.

“To the due date, we have

received an updated station with
a trained professional staff, and
the city of Blagoveshchensk has
gotten heat from the new unit of
power station”, CEO of PJSC “RAO

Energy Systems of the East”
Sergey Tolstoguzov said.

At the same time with con-

struc tion of Blagoveshcensk CHP,
there was a serious staff’s prepa-
ration in order to work with a new
equipment. The staff had to get
special knowledge  in order to
understand the particular features
of the new software and hardware
complex of the main control
board. Experts from manufacturer
of the boiler and the turbine set
came and made the explanations
about pecu

liar properties of the

equipment. Power engineers par-
ti cipated in the starting-up and
adjustment of the equipment ac-
tively during educational pro-
cess. Today they control ope-
rating modes of the equipment
successfully. 70 new employees
participate in the operation of the
new electrical power unit.

After the commissioning of

the second stage of Blago vesh-
chen skaya CHP, the power plant
has increased heat capacity by
a quarter and electric capacity
almost in one and a half time. This
is a very serious volume. More
precisely, installed capacity of
CHP has increased by 120 MW
and has become 400 MW. At
the same time heat capacity has
increased by 188 Gcal/h and has
become 1005 Gcal/h.

Annual output of electric ener-

gy will grow by 464 million kW•h
and reach a value of 1.468 million
kW•h. Annual output of heat
energy will increase by 730 Gcal
and reach a value of 2854 Gcal.

Start of the second stage

of CHP has already given the

fi

 rst results. It has provided the

opportunity to connect new
consumers to the central heating.
There is a plan to connect
13 facilities (5 apartment houses
and 4 administrative buildings)
with heat load of 5,351 Gcal/h
during 2016. The preliminary
permit has given for connection
of housing estate “Ignatievskaya
usadba”, “Peter” district, twelve
residential complexes and one
sport complex, as well as the
greenhouses with an area of
6 hectares.

The turbine set number 4 is ready to produce

electrical energy for Blagoveshchensk city
